Bridge Designs



  1. The first design was based off the Fink design. The many intersections proved too difficult to replicate for a model and was dismissed.
  2. The second design, which our model was built off, is a Warren bridge. The model itself featured a variant of which the Warren design is stacked into 2 layers with vertical supports.
  3. The third design was a combination of the Fink and Warren design. Due to the same complexities as making a Fink bridge design, the idea was also put aside.
